Swivel Seals
PZ800
Design Introduction
Kintowe PZ800 swivel pressure seal is designed specifically for hydraulic swivels . It’s manufactured in the high performance polyurethane KINTOWE ®01 and polyformaldehyde anti-extrusion ring.
PZ800 is designed for double acting conditions. Designs are available for piston or rod applications.
Advantages
●Low friction
●Low abrasion and good wear resistance
●No rotation within the groove
●Easy installation
Specification
| Rod Seals | ||||
| Фd1 | ФD1 | L1 | PART No. | Remark |
| 25 | 32.5 | 3.2 | PZ8000250 | 不带挤出环 |
| 32 | 39.5 | 3.2 | PZ8000320 | 不带挤出环 |
| 36 | 43.5 | 3.2 | PZ8000360 | 不带挤出环 |
| 40 | 51 | 4.2 | PZ8000400 | 不带挤出环 |
| 45 | 56 | 4.2 | PZ8000450 | 不带挤出环 |
| 70 | 80 | 5.0 | PZ8000700 | 不带挤出环 |
| 100 | 111 | 4.2 | PZ8001000 | |
| 100 | 115 | 6.3 | PZ8001001 | |
| 130 | 145.5 | 6.3 | PZ8001300 | |
| Pistion Seals | ||||
| ФD1 | Фd1 | L1 | PART No. | |
| 80 | 69.3 | 4.2 | PZ8000800 | 不带挤出环 |
| 90 | 79.3 | 4.2 | PZ8000900 | 不带挤出环 |
| 145 | 129.5 | 6.3 | PZ8001450 | |
| 160 | 144.5 | 6.3 | PZ8001600 | |
| 180 | 164.5 | 6.3 | PZ8001800 | |
